·Model:SA-PF-C ·Usage:Supply Air ·Material:Inherently Flame-retardant Polyester ·Color:light gray or custom other colors · Weight:220g/sm. Thickness: 0.35mm· · Shape:Round(Circular) · Air Distribute Type:Small Holes or Microporous · Suspension:H-Track/ Aluminum Rail System/SteelWire Cable System · Key Features:Lightweight, antibacterial, washable,flame retardant grade B1
· Model:SA-PF-C-NJ · Usage:Supply Air · Material:Inherently Flame-retardant Polyester · Color:light gray or custom other colors · Shape:Round(Circular) · Air Distribute Type:Nozzles · Suspension:H-Track Aluminum Rail System/Steel Wire Cable System
Model:SA-PF-SC ·Usage:Supply Air Material:Inherently Flame-retardant Polyester · Weight:220g/sm. Thickness: 0.35mm · Shape:Half Round(design for low height space) · Color:Light gray or custom other colors · Air Distribute Type:Small Holes/Microporous or Custom Nozzles · Suspension:Aluminum Rail System · Key Features:Lightweight, antibacterial, washable,flame retardant grade B1
·Model:SA-IF-C ·Usage:Are mainly used for transition segments where air of a certain temperature must be supplied into the emission area, keeping in account the loss of heat energy along the air duct's entire length. Such a system provides a means to minimize changes in temperature along the air duct. ·Material:external polyester+middle 10/15/25mm thickness Rubber and Plastic Thermal Insulation material+Internal Glass Fiber ·Shape:Round ·Color:Gray ·Key Features: lower heating conductivity coefficient, energy saving, precise temperature control, reducing heating and cooling loss
· Model:RA-IF-R · Usage:Return Air · Material:Polyester+Insulation Material+Glass Fiber · Weight:0.8kg/sm-1.4kg/sm .Thickness of insulation: custom 15/20/25mm ·Shape:Rectangular ·Color:gray · Vents Type:ABS Vents or Louver · Suspension:Aluminum Rail System · Key Features: lower heating conductivity coefficient,energy saving, precise temperature control, reducingheating and cooling loss
·Model:SA-IF-O-V ·Application:Using in conceled space, such asmezzanine and false ceiling to supply air or return air ·Material:Polyester+Insulation material+Glass Fiber· ·Weight:0.8kg/sm-1.4kg/sm ·Thickness of insulation: custom 15/20/25mm ·Shape:Custom Oval/Round/Rectangular ·Air Distribute Type:ABS Vents or Air diffusers · Suspension:Rod Suspension System · Key Features: lower heating conductivity coefficient,energy saving, precise temperature control, reducingheating and cooling loss
Model:SA-IF-C-AV Material:surface polyester+middle 10/15/25mm thickness Rubber and Plastic Thermal Insulation material+inner Glass Fiber Shape:Round Color:Gray Usage:Supply Air Air Distribute Type:ABS Vents Key Features: lower heating conductivity coefficient, energy saving, precise temperature control, reducing heating and cooling loss
· Model: SA-FG-C · Usage:Supply Air, Ideal choice for projects where the building code forbids any combustible materials in the HVAC plenum or workspace. · Material:Incombustible Glass Fiber · Color:Gray · Weight:490g/sm . Thickness: 0.45mm · Shape:Round/Half round · Suspension:H-Track Aluminum Rail System/SteelWire Cable System · Key Features:Lightweight, antibacterial, corrosion resistance, fire retardant grade A2
Model:SA-IF-O · Usage:Supply Air Material:Polyester+Insulation Material+Glass Fiber · Color:Gray · Weight:0.8kg/sm-1.4kg/sm . Thickness: 15/20/25mm · Shape:Oval(design for low height space) · Air Distribute Type:Small Holes · Suspension:Rod Suspension System ·Key Features: lower heating conductivity coefficient,energy saving, precise temperature control, reducingheating and cooling loss
· Model:SA-IF-R · Usage:Supply Air · Material:Polyester+Insulation Material+Glass Fiber ·Color:Gray · Weight:0.8kg/sm-1.4kg/sm . Thickness: 15/20/25mm . Shape:Rectangular(design for low height space) · Air Distribute Type:Small Holes · Suspension:Rod Suspension System · Key Features: lower heating conductivity coefficient,energy saving, precise temperature control, reducingheating and cooling loss
·Model:SA-PF-C-NS ·Usage:Supply Air · Material:Inherently Flame-retardant Polyester · Color:light gray or custom other colors · Weight:220g/sm. Thickness: 0.35mm · Shape:Round(Circular) · Air Distribute Type:Small Holes+Nozzles · Suspension:H-Track Aluminum Rail System/SteelWire Cable System · Key Features:Lightweight, antibacterial, washable,flame retardant grade B1
· Model:SA-PF-R · Usage:Supply Air · Material:Inherently Flame-retardant Polyester · Color:light gray or custom other colors · Weight:220g/sm. Thickness: 0.35mm · Shape:Rectangular(design for low height space) ·Air Distribute Type:Small ·Holes/Microporous or Custom Nozzles · Key Features:Lightweight, antibacterial, washable,flame retardant grade B1
